Used Sterlco Model: G9016-J1 36 (18,18) kW Single Zone Portable Hot Oil Process Heater Temperature Control Unit with Cooling Water Circuit

StatusAvailable
We offer for sale, subject to availability, prior sale and the terms listed below:
ManufacturerSterlco
ModelG9016-J1
Size36 (18,18) kW
Inventory NumberDCM-5660

Sterlco - G9016-J1 36 (18,18) kW Single Zone Portable Hot Oil Process Heater Temperature Control Unit with Cooling Water Circuit, West 4100 Controls

View Available Hot Oil Units

Questions? Call (847) 360-9170 and mention DCM-5660.

Features & Accessories

  • Call us on our Hot Oil Temperature Control Unit Hot Line 7:00 AM to 7:00 PM at 1-847-360-9170 Extension 2
  • West 4100 Microprocessor Controller
  • Alarms for low fluid pressure, pump rotation, over temperature
  • Set points for Process, High Alarm, Low Alarm
  • Displays for Process Temperature, Return Temperature and Temperature Difference
  • Unit is on casters for easy movement

Item Specifications for DCM-5660

USMetric
TOTAL KW:36 KW36 KW
Watts Per Heater (2 EACH):18 kW18 kW
Pump Motor Size:3 HP @ 1,725 RPM2.23 KW @ 1,725 RPM
Flow Rate:18 gallons per minute68 liters per minute
Connection size/type:3/4 inch NPT19.05 mm NPT
Maximum Operating Temperature:550 degrees F288 degrees C
Overall Size (L x W x H):44 x 24 x 62 inches1118 x 610 x 1575 mm
Full Load Amps @ 480/3/60:48 AMPS48 AMPS
Approximate Shipping Weight:950 pounds430 kG

Documents

Description

Used, Sterlco Model G9016-J1 36 (18,18) kW Single Zone Portable Hot Oil Process Heater Temperature Control Unit with Cooling Water Circuit For_Sale, Features Include: West 4100 Microprocessor Controller, Alarms for low fluid pressure, pump rotation, over temperature, Set points for Process, High Alarm, Low Alarm, Displays for Process Temperature, Return Temperature and Temperature Difference, Unit is on casters for easy movement, West 4100 controls, second Hand, DCM-5660
