Used Ube Model: VSC1250 1250 Metric Ton Vertical Cold Chamber Aluminum High Pressure Squeeze Cast or Semi-Solid Die Casting Machine

StatusAvailable
We offer for sale, subject to availability, prior sale and the terms listed below:
ManufacturerUbe
ModelVSC1250
Size1250 Metric Ton
Inventory NumberDCM-3593

Ube - VSC1250 1250 Metric Ton Vertical Cold Chamber Aluminum High Pressure Squeeze Cast or Semi-Solid Die Casting Machine, Ube Relay Controls

View Available Cold Chamber Die Casting Machines

Questions? Call (847) 360-9170 and mention DCM-3593.

Item Specifications for DCM-3593

USMetric
Locking Force:1377.88 Tons1250 Metric Tons
Tie Bar Clearance:53 x 42 inches1350 x 1070 mm
Minimum Die Height:35.43 inches900 mm
Die Opening Force:82.6 Ton75 Ton
Die Stroke (maximum):35.43 inches900 mm
Moving Platen Size (vertical x horizontal):83 x 72.5 inches2120 x 1840 mm
Shot Position:centercenter
Shot Injection Cyl Stroke:44 inches1120 mm
Injection Force220 tons200 tons
Shot Injection Speed:11.81 inch/sec4.5 m/sec
Ejector Force:40.78 ton37 ton
Ejector Stroke (max):3.14 inches80 mm

Description

Used, Ube Model VSC1250 1250 Metric Ton Vertical Cold Chamber Aluminum High Pressure Squeeze Cast or Semi-Solid Die Casting Machine For_Sale, Features Include:, Ube Relay controls, second Hand, DCM-3593
