Used Mokon Model: H52112-03 12 KW Single Zone Portable Hot Oil Process Heater Temperature Control Unit with Cooling Water Circuit
1 / 43| Status | Sold |
|---|---|
| Manufacturer | Mokon |
| Model | H52112-03 |
| Size | 12 KW |
| Inventory Number | DCM-5608 |
Mokon - H52112-03 12 KW Single Zone Portable Hot Oil Process Heater Temperature Control Unit with Cooling Water Circuit, Eurotherm 3216 Solid State Digital Temperature Controller with PID Capability Controls
Questions? Call (847) 360-9170 and mention DCM-5608.
Features & Accessories
- NOTE: Unit was originally shipped from the factory set for 230 volts, unit was field updated to 460 volts
- Eurotherm 3216 Solid State Digital Temperature Controler with PID Capability
- Equipped with Water Cooling Circuit controlled by the Eurotherm 3216
- HTF 500 Series
- Built-in pump pressure relief valve
- Mokon Dependability
- Unit on casters for easy movement
Item Specifications for DCM-5608
| US | Metric | |
| Main Heater Power (Zone #1): | 12 KW | 12 KW |
| Pump Motor Size (Zone #1): | 2 HP | 1.5 kW |
| Flow Rate (Zone #1): | 10 gallons per minute | 37.85 liters per minute |
| Connection size/type (Zone #1): | 1 inch NPT | 25.4 mm NPT |
| Maximum Operating Temperature: | 500 degrees F | 260 degrees C |
| Overall Size (L x W x H): | 55 x 16 x 48 inches | 1397 x 406 x 1219 mm |
| Full Load Amps @ 460/3/60: | 17.75 amp | 17.75 amp |
| Weight: | 460 lbs | 209 kg |
Video
Documents
Description
Used, Mokon Model H52112-03 12 KW Single Zone Portable Hot Oil Process Heater Temperature Control Unit with Cooling Water Circuit For_Sale, Features Include: Eurotherm 3216 Solid State Digital Temperature Controler with PID Capability, Equipped with Water Cooling Circuit controlled by the Eurotherm 3216, HTF 500 Series, Built-in pump pressure relief valve, Mokon Dependability, Unit on casters for easy movement, Eurotherm 3216 Solid State Digital Temperature Controller with PID Capability controls, second Hand, DCM-5608
