Used ABB Model: IRB 4400 M2000 45 Kilogram Six Axis Foundry Rated Industrial Robot
1 / 4| Status | Available |
|---|---|
| We offer for sale, subject to availability, prior sale and the terms listed below: | |
| Manufacturer | ABB |
| Model | IRB 4400 M2000 |
| Size | 45 Kilogram |
| Inventory Number | DCM-6053 |
ABB - IRB 4400 M2000 45 Kilogram Six Axis Foundry Rated Industrial Robot, Controls
Questions? Call (847) 360-9170 and mention DCM-6053.
Features & Accessories
- Take Your Die Casting Die Spraying and Casting Extraction Process to the Next Level - Performance only achievable using a High Capacity/Long Reach Six Axis Industrial Robot
- Fast maneuverability
- Medium to Heavy Payload Capability
- Renowned ABB Parts and Service
- Configured with Hardware for Automatic Die Spray including Spray Regulators, Manifolds, Nozzles plus Automatic Parts Extracting - Including Gripper for Extracting the Die Casting from the Die Cast Machine and Loading Casting into Trim Press
Item Specifications for DCM-6053
| US | Metric | |
| Number of Axis: | 6 | 6 |
| Payload Capacity: | 99 pounds | 45 kg |
| Reach: | 77 inches | 1960 mm |
| Axis 1 Robot Motion Range: | +/- 330 degrees | +/- 330 degrees |
| Axis 2 Robot Motion Range: | +/- 165 degrees | +/- 165 degrees |
| Axis 3 Robot Motion Range: | +/- 125 degrees | +/- 125 degrees |
| Axis 4 Robot Motion Range: | +/- 400 degrees | +/- 400 degrees |
| Axis 5 Robot Motion Range: | +/- 240 degrees | +/- 240 degrees |
| Axis 6 Robot Motion Range: | +/- 800 degrees | +/- 800 degrees |
| Repeatability: | +/- 0.00276 inches | +/- 0.07 mm |
Optional Equipment Available with Machine at Additional Cost (Click on item to view)
- Metal Mechanics Model: MM-50 50 Ton Four Column (Post) Vertical Hydraulic Die Casting Trim Press DCM-6008
- Return To Pace Black Creek DCM #7 DCM-6047
- PCDC Model: PCDC-QT 280 280 Gallon Quench Tank Capacity Quench Tanks used for quenching die castings DCM-6048
- PCDC Model: PCDC-SC 24 Inch Wide by 8 foot long Metal Chain Plate Conveyor Belt with Forced Air Cooling Fans and Tunnel for Die Cast and Foundry Applications DCM-6049
- PCDC Model: PCDC-GNC 24 Inch Wide by 14 foot long Metal Chain Plate Conveyor Belt with Forced Air Cooling Fans and Tunnel for Die Cast and Foundry Applications DCM-6050
- F.W. Schaefer Model: FWS-800 800 Pounds per Hour Melt Rate Reverberatory Type Wet Bath Stationary Aluminum Melting and Holding Furnace DCM-6051
- Rimrock Model: 305 50 Pound Pour Capacity Multi-Link Automatic Ladle for Non-Ferrous Aluminum and Brass Die Casting and Foundry Operations DCM-6052
- PCDC Model: PCDC-30x156 30 Inch Wide by 13 foot long Metal Chain Plate Conveyor Belt with Forced Air Cooling Fans and Tunnel for Die Cast and Foundry Applications DCM-6054
Description
Used, ABB Model IRB 4400 M2000 45 Kilogram Six Axis Foundry Rated Industrial Robot For_Sale, Features Include: Fast maneuverability, Medium to Heavy Payload Capability, Renowned ABB Parts and Service, Configured with Hardware for Automatic Die Spray including Spray Regulators, Manifolds, Nozzles plus Automatic Parts Extracting - Including Gripper for Extracting the Die Casting from the Die Cast Machine and Loading Casting into Trim Press, controls, second Hand, DCM-6053
PURCHASER'S (Buyer's) RESPONSIBILITY AND INDEMNITY: Used machines, equipment or any part thereof, may not incorporate approved activating mechanisms, operator safety devices or safety guards as required by OSHA or otherwise. It shall be a Purchaser's (Buyer's) responsibility to ensure that any and all merchandise or equipment purchased from Die Cast Machinery, LLC or its affiliates is installed and operated in a proper and safe manner. Purchaser (Buyer) also acknowledges that it may have to install or change guards, safeties, warnings or other components to ensure that the merchandise or machines purchased will conform to all laws, codes, regulations, ordinances, statutes, insurance requirements and industry standards. Purchaser agrees to defend, indemnify and hold harmless Die Cast Machinery, LLC from and against all suits, claims, costs, damages and expenses, including, but not limited to, reasonable attorneys' fees, arising out of, or in connection with, the transportation, purchase, ownership, or use of the merchandise or equipment sold hereunder. Information has been obtained from sources deemed reliable, buyers should avail themselves of the opportunity to inspect the items before purchase.
