Used Mokon Model: H44212-16 24 kW (12 kW per zone) Dual (two) Zone Portable Hot Oil Process Heater Temperature Control Unit with Cooling Water Circuit
1 / 19| Status | Sold |
|---|---|
| Manufacturer | Mokon |
| Model | H44212-16 |
| Size | 24 kW (12 kW per zone) |
| Inventory Number | DCM-4871 |
Mokon - H44212-16 24 kW (12 kW per zone) Dual (two) Zone Portable Hot Oil Process Heater Temperature Control Unit with Cooling Water Circuit, Eurotherm and Barber-Cohman Controls
Questions? Call (847) 360-9170 and mention DCM-4871.
Features & Accessories
- HTF 500 Series Mokon Dependability
- Water Cooling Circuit
- Built-in pump pressure relief valve
- Unit on casters for easy movement
- Eurotherm and Barber-Cohman Controller
Item Specifications for DCM-4871
| US | Metric | |
| Main Heater Power (Zone #1): | 12 kW | 12 kW |
| Pump Motor Size (Zone #1): | 1 HP | .75 KW |
| Flow Rate (Zone #1): | 10 gallons per minute | 38 liters per minute |
| Connection size/type (Zone #1): | 1 inch NPT | 1 inch NPT |
| Main Heater Power (Zone #2): | 12 kW | 12 kW |
| Pump Motor Size (Zone #2): | 1 HP | .75 KW |
| Flow Rate (Zone #2): | 10 gallons per minute | 38 liters per minute |
| Connection size/type (Zone #2): | 1 inch NPT | 1 inch NPT |
| Maximum Operating Temperature: | 500 degrees F | 260 degrees C |
| Overall Size (L x W x H): | 45 x 31 x 51 inches | 1143 x 787 x 1295 mm |
| Approx. Weight: | 777 pounds | 352 kg |
| Full Load Amps @ 460/3/60: | 34.0 amp | 34.0 amp |
Video
Documents
Description
Used, Mokon Model H44212-16 24 kW (12 kW per zone) Dual (two) Zone Portable Hot Oil Process Heater Temperature Control Unit with Cooling Water Circuit For_Sale, Features Include: HTF 500 Series Mokon Dependability, Water Cooling Circuit, Built-in pump pressure relief valve, Unit on casters for easy movement, Eurotherm and Barber-Cohman Controller, Eurotherm and Barber-Cohman controls, second Hand, DCM-4871
