Used Mokon Model: H54148HV 48 KW Single Zone Portable Hot Oil Process Heater Temperature Control Unit with Cooling Water Circuit
1 / 18| Status | Sold |
|---|---|
| Manufacturer | Mokon |
| Model | H54148HV |
| Size | 48 KW |
| Inventory Number | DCM-4454 |
Mokon - H54148HV 48 KW Single Zone Portable Hot Oil Process Heater Temperature Control Unit with Cooling Water Circuit, Controls
Questions? Call (847) 360-9170 and mention DCM-4454.
Features & Accessories
- Water Cooling Circuit
- HTF 500 Series Mokon Dependability
- Unit on casters for easy movement
- Built-in pump pressure relief valve
- Eurotherm Controls
Item Specifications for DCM-4454
| US | Metric | |
| Main Heater Power (Zone #1): | 48 KW | 48 KW |
| Pump Motor Size (Zone #1): | 2 HP | 1.49 kW |
| Flow Rate (Zone #1): | 20 gallons per minute | 75.7 liters per minute |
| Connection size/type (Zone #1): | 1 inch NPT | 25.4 mm NPT |
| Maximum Operating Temperature: | 500 degrees F | 260 degrees C |
| Overall Size (L x W x H): | 41 x 15 x 50 inches | 1041 x 381 x 1270 mm |
| Full Load Amps @ 460/3/60: | 63.5 amp | 63.5 amp |
Video
Documents
Description
Used, Mokon Model H54148HV 48 KW Single Zone Portable Hot Oil Process Heater Temperature Control Unit with Cooling Water Circuit For_Sale, Features Include: Water Cooling Circuit, HTF 500 Series Mokon Dependability, Unit on casters for easy movement, Built-in pump pressure relief valve, Eurotherm Controls, controls, second Hand, DCM-4454
