Used Sterling Trim Press Model: 30 Ton Four Column (post) Horizontal Hydraulic Die Cast Trim Press
1 / 4| Status | Sold |
|---|---|
| Manufacturer | Sterling Trim Press |
| Size | 30 Ton |
| Inventory Number | DCM-3423 |
Sterling Trim Press - 30 Ton Four Column (post) Horizontal Hydraulic Die Cast Trim Press, Controls
View Available Horizontal Trim Presses
Questions? Call (847) 360-9170 and mention DCM-3423.
Features & Accessories
- Hydraulic Ejector Plate
- Automatic Lubrication
- T-Slotted Moving and Bed Platens
- Mechanical Ejector Bars
Item Specifications for DCM-3423
| US | Metric | |
| Pressing Tonnage: | 30 tons | 27.22 tons |
| Number of Columns: | 4 | 4 |
| Daylight: | 32 inches | 812.8 mm |
| Stroke: | 18 inches | 457.2 mm |
| Shut Height: | 14 inches | 355.6 mm |
| Clearance between Tie bars (Vertical): | 32 inches | 812.8 mm |
| Clearance between Tie bars (Horizontal): | 30 inches | 762 mm |
| Bed Size (Vertical x Horizontal): | 42 x 40 inches | 1066.8 x 1016 mm |
Description
Used, Sterling Trim Press Model 30 Ton Four Column (post) Horizontal Hydraulic Die Cast Trim Press For_Sale, Features Include: Hydraulic Ejector Plate, Automatic Lubrication, T-Slotted Moving and Bed Platens, Mechanical Ejector Bars, controls, second Hand, DCM-3423
